Firewal

The term firewall originally referred to a wall intended to confine a fire or potential fire within a building. Later uses refer to similar structures, such as the metal sheet separating the engine compartment of a vehicle or aircraft from the passenger compartment.
Firewall technology emerged in the late 1980s when the Internet was a fairly new technology in terms of its global use and connectivity. The predecessors to firewalls for network security were the routers used in the late 1980s:Clifford Stoll's discovery of German spies tampering with his systemBill Cheswick's "Evening with Berferd" 1992 in which he set up a simple electronic "jail" to observe an attacker
In 1988, an employee at the NASA Ames Research Center in California sent a memo by email to his colleagues[4] that read, "We are currently under attack from an Internet VIRUS! It has hit Berkeley, UC San Diego, Lawrence Livermore,Stanford, and NASA Ames."
The Morris Worm spread itself through multiple vulnerabilities in the machines of the time. Although it was not malicious in intent, the Morris Worm was the first large scale attack on Internet security; the online community was neither expecting an attack nor prepared to deal with one.

First generation: packet filters

The first paper published on firewall technology was in 1988, when engineers from Digital Equipment Corporation (DEC) developed filter systems known as packet filter firewalls. This fairly basic system was the first generation of what is now a highly involved and technical internet security feature. At AT&T Bell Labs, Bill Cheswick and Steve Bellovin were continuing their research in packet filtering and developed a working model for their own company based on their original first generation architecture.

Packet filters act by inspecting the "packets" which are transferred between computers on the Internet. If a packet matches the packet filter's set of filtering rules, the packet filter will drop (silently discard) the packet or reject it (discard it, and send "error responses" to the source).
This type of packet filtering pays no attention to whether a packet is part of an existing stream of traffic (i.e. it stores no information on connection "state"). Instead, it filters each packet based only on information contained in the packet itself (most commonly using a combination of the packet's source and destination address, its protocol, and, for TCP andUDP traffic, the port number).
TCP and UDP protocols constitute most communication over the Internet, and because TCP and UDP traffic by convention uses well known ports for particular types of traffic, a "stateless" packet filter can distinguish between, and thus control, those types of traffic (such as web browsing, remote printing, email transmission, file transfer), unless the machines on each side of the packet filter are both using the same non-standard ports.

Second generation: "stateful" filter

From 1989–1990 three colleagues from AT&T Bell Laboratories, Dave Presetto, Janardan Sharma, and Kshitij Nigam, developed the second generation of firewalls, calling themCircuit-level gateways.
Second-generation firewalls perform the work of their first-generation predecessors but operate up to layer 4 (transport layer) of the OSI model. This is achieved by retaining packets until enough information is available to make a judgement about its state. Known as stateful packet inspection, it records all connections passing through it and determines whether a packet is the start of a new connection, a part of an existing connection, or not part of any connection. Though static rules are still used, these rules can now contain connection state as one of their test criteria.

Third generation: application layer

Marcus Ranum, Wei Xu, and Peter Churchyard developed an Application Firewall known as Firewall Toolkit (FWTK). In June 1994, Wei Xu extended the FWTK with the Kernel enhancement of IP filter and socket transparent. This was known as the first transparent Application firewall, released as a commercial product of Gauntlet firewall at Trusted Information Systems. Gauntlet firewall was rated one of the number 1 firewalls during 1995–1998.

The key benefit of application layer filtering is that it can "understand" certain applications and protocols (such as File Transfer Protocol (FTP), Domain Name System (DNS), orHypertext Transfer Protocol (HTTP)). This is useful as it is able to detect if an unwanted protocol is attempting to bypass the firewall on an allowed port, or detect if a protocol is being abused in any harmful way. As of 2012, the so-called next-generation firewall (NGFW) is nothing more than the "widen" or "deepen" inspection at application-stack. For example, the existing deep packet inspection functionality of modern firewalls can be extended to include i) Intrusion prevention systems (IPS); ii) User identity integration (by binding user IDs to IP or MAC addresses for "reputation"); and/or iii) Web Application Firewall (WAF). WAF attacks may be implemented in the tool "WAF Fingerprinting utilizing timing side channels" (WAFFle).

Types

There are different types of firewalls depending on where the communication is taking place, where the communication is intercepted and the state that is being traced.

Network layer or packet filters

Network layer firewalls, also called packet filters, operate at a relatively low level of the TCP/IP protocol stack, not allowing packets to pass through the firewall unless they match the established rule set. The firewall administrator may define the rules; or default rules may apply. The term "packet filter" originated in the context of BSD operating systems.
Network layer firewalls generally fall into two sub-categories, stateful and stateless. Stateful firewalls maintain context about active sessions, and use that "state information" to speed packet processing. Any existing network connection can be described by several properties, including source and destination IP address, UDP or TCP ports, and the current stage of the connection's lifetime (including session initiation, handshaking, data transfer, or completion connection). If a packet does not match an existing connection, it will be evaluated according to the ruleset for new connections. If a packet matches an existing connection based on comparison with the firewall's state table, it will be allowed to pass without further processing.

Application-layer

Application-layer firewalls work on the application level of the TCP/IP stack (i.e., all browser traffic, or all telnet or ftp traffic), and may intercept all packets traveling to or from an application. They block other packets (usually dropping them without acknowledgment to the sender).
On inspecting all packets for improper content, firewalls can restrict or prevent outright the spread of networked computer worms and trojans. The additional inspection criteria can add extra latency to the forwarding of packets to their destination.
